Tutorial 02: System services

Overview

This tutorial extends Tutorial 01 with a Screen render callback, named image resources stored in a CDC archive, a DebugWindow and the built-in Console. The logic remains fixed at 20 updates per second while rendering runs as often as the selected renderer allows.

Final result

CRM64Pro Tutorial 02 final result

Runtime controls

• Cursor keys: Move the ship image.
• D: Show or hide the debug window.
• Grave key: Show or hide the built-in console.
• Any key or mouse click: Write the input event to the log.
• Q or ESC: Exit the tutorial.

Prerequisites

• CRM64Pro GDK installed and configured with a supported C++17 compiler.
• Tutorial package downloaded and fully extracted, preserving its folder structure.
• Complete Tutorial 01 or understand its setup and fixed logic loop.
• Included assets available under bin/Base/: tutorial_bg.png, tutorial_ship.png.
• Write access to the platform output directory for Tutorial.cdc and the log.

What you will learn

• Register a Screen render callback.
• Save named Image resources to a CDC archive.
• Load Image resources from a CDC archive by name.
• Create a DebugWindow and watch live variables.
• Use the built-in Console.
• Keep fixed-rate logic independent from rendering.

Step by step

1. Configure independent logic and rendering

A render rate of zero lets the Screen render whenever possible. The fixed 20 Hz logic rate still controls movement, keeping gameplay speed independent from the render frame rate.

// Fixed-rate timing.
// Render rate 0 lets the screen render as often as possible. Logic rate controls movement.
static const Sint32 iLogicRate = 20;
static const Sint32 iRenderRate = 0;

2. Register the render callback

Main::update() invokes the callback when a render frame is ready. The callback receives the tutorial state, resolves the current Image resources and draws the frame.

// Screen render callback.
// Main::update() calls this when the screen is ready to render.
static Sint32 renderWrapper(Sint32, void* pObj)
{
    TutorialState* pState = static_cast<TutorialState*>(pObj);
    if(!pState) return 0;

    ImageMgr& mImageMgr = Main::instance().imageMgr();
    Image* pBgImage = mImageMgr.get(pState->idBgImage);
    Image* pPlayerImage = mImageMgr.get(pState->idPlayerImage);
    renderFrame(pBgImage, pPlayerImage, *pState);

    return 0;
}

mLog.msg(LL_INFO, "  Set render callback ... ");
if(!pScreen->setRenderCallback([&state](Sint32 iMode) { return renderWrapper(iMode, &state); }))
{
    logTaskFailed(mLog);
    Main::terminate();
    return -1;
}
logTaskOk(mLog);

3. Choose the CDC archive

The image save calls create Tutorial.cdc if needed or update its named resources when it already exists. They open the archive for writing and release it after saving, so the tutorial does not remove an existing archive.

#define OUTPUT_CDC OUTPUTDIR"Tutorial.cdc"

4. Save named image resources

Each PNG is loaded as a normal Image, saved to the CDC under a stable resource name, then closed because the file-backed object is no longer needed.

// Load the background from a normal image file.
mLog.msg(LL_INFO, "  Load background image: %s ... ", RESOURCE_BG_IMAGE);
Sint32 idBgFile = mC64.imageMgr().loadFromFile(RESOURCE_BG_IMAGE, "tutorialSystemBgFile");
Image* pBgFileImage = mC64.imageMgr().get(idBgFile);
if(idBgFile < 0 || pBgFileImage == nullptr)
{
    logTaskFailed(mLog, idBgFile);
    Main::terminate();
    return -1;
}
logTaskOk(mLog);

// Save the background first.
mLog.msg(LL_INFO, "  Save background image to CDC ... ");
if(pBgFileImage->save(OUTPUT_CDC, RESOURCE_BG_CDC_NAME) < 0)
{
    logTaskFailed(mLog);
    Main::terminate();
    return -1;
}
mC64.imageMgr().close(idBgFile);
logTaskOk(mLog);

The ship follows the same load, save and close sequence with RESOURCE_PLAYER_CDC_NAME.

5. Load images by resource name

ImageMgr loads the saved resources from the CDC by archive path and resource name. The order of blocks inside the archive does not matter.

// Load the background by its CDC resource name.
mLog.msg(LL_INFO, "  Load background image from CDC ... ");
state.idBgImage = mC64.imageMgr().load(OUTPUT_CDC, RESOURCE_BG_CDC_NAME);
if(state.idBgImage < 0)
{
    logTaskFailed(mLog, state.idBgImage);
    Main::terminate();
    return -1;
}
logTaskOk(mLog);

// Load the ship by its CDC resource name. Load order is not significant.
mLog.msg(LL_INFO, "  Load ship image from CDC ... ");
state.idPlayerImage = mC64.imageMgr().load(OUTPUT_CDC, RESOURCE_PLAYER_CDC_NAME);
if(state.idPlayerImage < 0)
{
    logTaskFailed(mLog, state.idPlayerImage);
    Main::terminate();
    return -1;
}
logTaskOk(mLog);

6. Add the debug window

The DebugWindow keeps pointers to the watched values and displays their current contents. The values therefore remain members of TutorialState for the whole main loop.

// The DebugWindow displays live values while the program runs.
mLog.msg(LL_INFO, "  Create debug window ... ");
state.idDebugWindow = mC64.guiMgr().create("Debug", CRM64PRO_GUI_DEBUGWINDOW);
DebugWindow* pDebug = mC64.guiMgr().getDebugWindow(state.idDebugWindow);
if(!pDebug)
{
    logTaskFailed(mLog, state.idDebugWindow);
    Main::terminate();
    return -1;
}
pDebug->baseWidget().setPosition(Position(PH_RIGHT, -120), Position(PH_TOP, 10));
pDebug->addWatch("Player X", nullptr, &state.fPlayerX);
pDebug->addWatch("Player Y", nullptr, &state.fPlayerY);
pDebug->addWatch("Mouse X", nullptr, &state.fMouseX);
pDebug->addWatch("Mouse Y", nullptr, &state.fMouseY);
pDebug->addWatch("Logic frames", &state.iLogicFrames);
pDebug->baseWidget().show();
logTaskOk(mLog);

7. Use the built-in console

Main creates the default Console. Logging is already routed to it, and the tutorial prints a short ready message when the Console is available.

// Main creates the default Console. Log output is also sent there.
Console* pConsole = mC64.guiMgr().getConsole();
if(pConsole) pConsole->print("Tutorial 02: System ready. Press ` to toggle the console.\n");

8. Run fixed logic after event processing

Main::update() processes input and triggers rendering. Once it returns zero, the program performs one fixed logic update. A quit request exits before that last update.

if(!bRunning) break;
state.fMouseX = mC64.cursorMgr().getX();
state.fMouseY = mC64.cursorMgr().getY();
updateLogic(state, pPlayerImage, 1.0f / static_cast<float>(iLogicRate));

9. Close resources and inspect the CDC

The tutorial closes its GUI and image resources, opens the completed archive read-only to print its information, then closes it and terminates CRM64Pro.

// Close resources owned by this tutorial.
mLog.msg(LL_INFO, "\nCLEANUP\n");
mLog.msg(LL_INFO, "  Close debug window ... ");
mC64.guiMgr().close(state.idDebugWindow);
logTaskOk(mLog);
mLog.msg(LL_INFO, "  Close images ... ");
mC64.imageMgr().close(0);
logTaskOk(mLog);
mLog.msg(LL_INFO, "  Inspect CDC archive ... ");
const Sint32 idCDC = mC64.archiveMgr().load(OUTPUT_CDC);
if(idCDC < 0)
{
    logTaskFailed(mLog, idCDC);
    Main::terminate();
    return -1;
}
logTaskOk(mLog);
mC64.archiveMgr().info();
mLog.msg(LL_INFO, "  Close CDC archive ... ");
mC64.archiveMgr().close(idCDC);
logTaskOk(mLog);
Main::terminate();

Complete source

The tutorial source is authoritative. The following listing is included directly from validation/source/Tutorial_02_System.cpp.

/* ----------------------------------------------------------------------
    CRM64Pro GDK - Roberto Prieto
    Copyright (C) 2013-2026 MegaStorm Systems

    This software is provided 'as-is', without any express or implied
    warranty. In no event will the authors be held liable for any damages
    arising from the use of this software.

    Permission is granted to anyone to use this software for any purpose,
    including commercial applications, and to alter it and redistribute it
    freely, subject to the following restrictions:

    1. The origin of this software must not be misrepresented; you must not
       claim that you wrote the original software.
    2. Altered source versions must be plainly marked as such, and must not be
       misrepresented as being the original software.
    3. This notice may not be removed or altered from any source distribution.

------------------------------------------------------------------------
                        Tutorial 02: System
------------------------------------------------------------------------

    Overview:
    This tutorial extends Tutorial 01 Basic with a render callback, named CDC
    resources, the debug window and the built-in console.

    Key concepts:
    - Use a Screen render callback.
    - Save named Image resources to a CDC file.
    - Load Image resources from a CDC file by name.
    - Create a DebugWindow and add watched variables.
    - Use the built-in Console.
    - Keep the fixed logic update from Tutorial 01 Basic.

    Controls:
    - Cursor Keys: Move the ship image.
    - D: Toggle debug window.
    - Grave: Toggle console.
    - Any Key/Mouse: Logs events.
    - Q / ESC: Quit.

    Loop order:
    - Process input events.
    - Run one fixed logic update.
    - Let Main::update() call the screen render callback.
------------------------------------------------------------------------ */

#include "CRM64Pro.h"
#include "RunParameter.h"

using namespace CRM64Pro;

#define BASEDIR "Base/"
#ifdef CRM64PRO_PLATFORM_WINDOWS
#define OUTPUTDIR "Win64/"
#elif defined(CRM64PRO_PLATFORM_LINUX)
#define OUTPUTDIR "Linux/"
#elif defined(CRM64PRO_PLATFORM_MACOS)
#define OUTPUTDIR "macOS/"
#endif

#define RESOURCE_BG_IMAGE BASEDIR"tutorial_bg.png"
#define RESOURCE_PLAYER_IMAGE BASEDIR"tutorial_ship.png"
#define RESOURCE_BG_CDC_NAME "Tutorial_bg"
#define RESOURCE_PLAYER_CDC_NAME "Tutorial_ship"
#define OUTPUT_CDC OUTPUTDIR"Tutorial.cdc"

// Fixed-rate timing.
// Render rate 0 lets the screen render as often as possible. Logic rate controls movement.
static const Sint32 iLogicRate = 20;
static const Sint32 iRenderRate = 0;

// Window size and movement speed.
static const Sint32 iScreenW = 960;
static const Sint32 iScreenH = 540;
static const float fMoveSpeed = 220.0f;

// Values changed while the tutorial runs.
struct TutorialState
{
    Sint32 idBgImage = -1;
    Sint32 idPlayerImage = -1;
    Sint32 idDebugWindow = -1;
    float fPlayerX = 386.0f;
    float fPlayerY = 186.0f;
    float fMouseX = 0.0f;
    float fMouseY = 0.0f;
    Sint32 iLogicFrames = 0;
    bool bMoveLeft = false;
    bool bMoveRight = false;
    bool bMoveUp = false;
    bool bMoveDown = false;
};

// Keep a value inside the given range.
static float clampFloat(float fValue, float fMin, float fMax)
{
    if(fValue < fMin) return fMin;
    if(fValue > fMax) return fMax;
    return fValue;
}

// Helper functions used by the setup log messages.
static void logTaskOk(Log& mLog)
{
    mLog.msg(LL_DEBUG, "OK\n");
}

// Record a failed tutorial task.
static void logTaskFailed(Log& mLog, Sint32 iCode)
{
    mLog.msg(LL_ERROR, "FAILED (Code %d)\n", iCode);
}

// Record a failed tutorial task.
static void logTaskFailed(Log& mLog)
{
    mLog.msg(LL_ERROR, "FAILED\n");
}

// Move the ship image one fixed logic step.
static void updateLogic(TutorialState& rState, Image* pPlayerImage, float fDeltaTime)
{
    if(!pPlayerImage) return;

    float fDX = 0.0f;
    float fDY = 0.0f;

    if(rState.bMoveLeft) fDX -= fMoveSpeed * fDeltaTime;
    if(rState.bMoveRight) fDX += fMoveSpeed * fDeltaTime;
    if(rState.bMoveUp) fDY -= fMoveSpeed * fDeltaTime;
    if(rState.bMoveDown) fDY += fMoveSpeed * fDeltaTime;

    const float fMaxX = static_cast<float>(iScreenW - pPlayerImage->getWidth());
    const float fMaxY = static_cast<float>(iScreenH - pPlayerImage->getHeight());
    rState.fPlayerX = clampFloat(rState.fPlayerX + fDX, 0.0f, fMaxX);
    rState.fPlayerY = clampFloat(rState.fPlayerY + fDY, 0.0f, fMaxY);
    rState.iLogicFrames++;
}

// Draw the current frame.
static void renderFrame(Image* pBgImage, Image* pPlayerImage, const TutorialState& rState)
{
    if(pBgImage) pBgImage->render();

    if(pPlayerImage)
    {
        SDL_FRect rDst = {
            rState.fPlayerX,
            rState.fPlayerY,
            static_cast<float>(pPlayerImage->getWidth()),
            static_cast<float>(pPlayerImage->getHeight())
        };
        pPlayerImage->render(0, nullptr, &rDst);
    }
}

// Screen render callback.
// Main::update() calls this when the screen is ready to render.
static Sint32 renderWrapper(Sint32, void* pObj)
{
    TutorialState* pState = static_cast<TutorialState*>(pObj);
    if(!pState) return 0;

    ImageMgr& mImageMgr = Main::instance().imageMgr();
    Image* pBgImage = mImageMgr.get(pState->idBgImage);
    Image* pPlayerImage = mImageMgr.get(pState->idPlayerImage);
    renderFrame(pBgImage, pPlayerImage, *pState);

    return 0;
}

// Show or hide the debug window.
static void toggleDebugWindow(DebugWindow* pDebug)
{
    if(!pDebug) return;
    if(pDebug->baseWidget().status() == GS_SHOWN) pDebug->baseWidget().hide();
    else pDebug->baseWidget().show();
}

// Run the tutorial application and release its resources.
int main(int argc, char* argv[])
{
    eConfigRendererDriver eRenderer = CRD_SOFTWARE;
    if(!runParameterReadRender(argc, argv, eRenderer)) return 1;

    // Start CRM64Pro memory tracking before creating engine resources.
    // atexit() releases memory tracking data when the program exits.
    CMem::setStatsLevel(CMem::MSL_NORMAL);
    atexit(CMem::destroy);

    // Main gives access to the CRM64Pro managers.
    Main& mC64 = Main::instance();
    Log& mLog = *mC64.logMgr().get();

    TutorialState state;

    // Write log output to stdout and to a file under validation/bin.
    mLog.init("Tutorial_02_System", LL_DEBUG, LM_FILE | LM_STDOUT, OUTPUTDIR"Tutorial_02_System.log");

    mLog.msg(LL_INFO, "\nSETUP: screen and timing\n");

    // Initialize the timer before calling Main::update().
    // setRate() receives render frames per second, then logic frames per second.
    mLog.msg(LL_INFO, "  Initialize timer ... ");
    if(!mC64.timer().init())
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    mLog.msg(LL_INFO, "  Set frame rates (render=%d, logic=%d) ... ", iRenderRate, iLogicRate);
    if(!mC64.timer().setRate(iRenderRate, iLogicRate))
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    // Add a 1 ms idle delay inside Main::update().
    mC64.configMgr().setMTFriendly(1);

    // Configure and show the default screen.
    Screen* pScreen = mC64.configMgr().get();
    pScreen->setSize(iScreenW, iScreenH);
    pScreen->setDriver(eRenderer);
    pScreen->setTitle("CRM64Pro - Tutorial 02: System");

    mLog.msg(LL_INFO, "  Create screen (%dx%d) ... ", iScreenW, iScreenH);
    if(pScreen->show() < 0)
    {
        mLog.msg(LL_CRITICAL, "FAILED\n");
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    mLog.msg(LL_INFO, "  Set render callback ... ");
    if(!pScreen->setRenderCallback([&state](Sint32 iMode) { return renderWrapper(iMode, &state); }))
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    mLog.msg(LL_INFO, "\nRESOURCES: file images and CDC\n");

    // Load the background from a normal image file.
    mLog.msg(LL_INFO, "  Load background image: %s ... ", RESOURCE_BG_IMAGE);
    Sint32 idBgFile = mC64.imageMgr().loadFromFile(RESOURCE_BG_IMAGE, "tutorialSystemBgFile");
    Image* pBgFileImage = mC64.imageMgr().get(idBgFile);
    if(idBgFile < 0 || pBgFileImage == nullptr)
    {
        logTaskFailed(mLog, idBgFile);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    // Save the background first.
    mLog.msg(LL_INFO, "  Save background image to CDC ... ");
    if(pBgFileImage->save(OUTPUT_CDC, RESOURCE_BG_CDC_NAME) < 0)
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }
    mC64.imageMgr().close(idBgFile);
    logTaskOk(mLog);

    // Load the ship from a normal image file.
    mLog.msg(LL_INFO, "  Load ship image: %s ... ", RESOURCE_PLAYER_IMAGE);
    Sint32 idPlayerFile = mC64.imageMgr().loadFromFile(RESOURCE_PLAYER_IMAGE, "tutorialSystemPlayerFile");
    Image* pPlayerFileImage = mC64.imageMgr().get(idPlayerFile);
    if(idPlayerFile < 0 || pPlayerFileImage == nullptr)
    {
        logTaskFailed(mLog, idPlayerFile);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    // Save the ship second.
    mLog.msg(LL_INFO, "  Save ship image to CDC ... ");
    if(pPlayerFileImage->save(OUTPUT_CDC, RESOURCE_PLAYER_CDC_NAME) < 0)
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }
    mC64.imageMgr().close(idPlayerFile);
    logTaskOk(mLog);

    // Load the background by its CDC resource name.
    mLog.msg(LL_INFO, "  Load background image from CDC ... ");
    state.idBgImage = mC64.imageMgr().load(OUTPUT_CDC, RESOURCE_BG_CDC_NAME);
    if(state.idBgImage < 0)
    {
        logTaskFailed(mLog, state.idBgImage);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    // Load the ship by its CDC resource name. Load order is not significant.
    mLog.msg(LL_INFO, "  Load ship image from CDC ... ");
    state.idPlayerImage = mC64.imageMgr().load(OUTPUT_CDC, RESOURCE_PLAYER_CDC_NAME);
    if(state.idPlayerImage < 0)
    {
        logTaskFailed(mLog, state.idPlayerImage);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);

    Image* pPlayerImage = mC64.imageMgr().get(state.idPlayerImage);
    if(pPlayerImage == nullptr)
    {
        logTaskFailed(mLog);
        Main::terminate();
        return -1;
    }

    mLog.msg(LL_INFO, "\nTOOLS: debug window and console\n");

    // The DebugWindow displays live values while the program runs.
    mLog.msg(LL_INFO, "  Create debug window ... ");
    state.idDebugWindow = mC64.guiMgr().create("Debug", CRM64PRO_GUI_DEBUGWINDOW);
    DebugWindow* pDebug = mC64.guiMgr().getDebugWindow(state.idDebugWindow);
    if(!pDebug)
    {
        logTaskFailed(mLog, state.idDebugWindow);
        Main::terminate();
        return -1;
    }
    pDebug->baseWidget().setPosition(Position(PH_RIGHT, -120), Position(PH_TOP, 10));
    pDebug->addWatch("Player X", nullptr, &state.fPlayerX);
    pDebug->addWatch("Player Y", nullptr, &state.fPlayerY);
    pDebug->addWatch("Mouse X", nullptr, &state.fMouseX);
    pDebug->addWatch("Mouse Y", nullptr, &state.fMouseY);
    pDebug->addWatch("Logic frames", &state.iLogicFrames);
    pDebug->baseWidget().show();
    logTaskOk(mLog);

    // Main creates the default Console. Log output is also sent there.
    Console* pConsole = mC64.guiMgr().getConsole();
    if(pConsole) pConsole->print("Tutorial 02: System ready. Press ` to toggle the console.\n");

    mLog.msg(LL_INFO, "\nCONTROLS\n");
    mLog.msg(LL_INFO, "  [Q] / [ESC] Quit\n");
    mLog.msg(LL_INFO, "  [Arrow Keys] Move the ship image\n");
    mLog.msg(LL_INFO, "  [D] Toggle debug window\n");
    mLog.msg(LL_INFO, "  [`] Toggle console\n");
    mLog.msg(LL_INFO, "  Any key or mouse button logs the input event\n");
    mLog.msg(LL_INFO, "\nRUNNING\n");

    SDL_Event event;
    bool bRunning = true;
    while(bRunning)
    {
        // Main::update() processes input, runs internal GUI logic and calls the
        // screen render callback when a render frame is ready.
        while(mC64.update(&event))
        {
            if(event.type == SDL_EVENT_QUIT)
            {
                bRunning = false;
            }
            else if(event.type == SDL_EVENT_KEY_DOWN)
            {
                // SDL3 stores the key value in event.key.key.
                mLog.msg(LL_INFO, "  Key pressed: %s (%d)\n", SDL_GetKeyName(event.key.key), event.key.key);

                if(event.key.key == SDLK_Q || event.key.key == SDLK_ESCAPE)
                {
                    bRunning = false;
                }
                else if(event.key.key == SDLK_LEFT)
                {
                    state.bMoveLeft = true;
                }
                else if(event.key.key == SDLK_RIGHT)
                {
                    state.bMoveRight = true;
                }
                else if(event.key.key == SDLK_UP)
                {
                    state.bMoveUp = true;
                }
                else if(event.key.key == SDLK_DOWN)
                {
                    state.bMoveDown = true;
                }
                else if(event.key.key == SDLK_D)
                {
                    toggleDebugWindow(pDebug);
                }
            }
            else if(event.type == SDL_EVENT_KEY_UP)
            {
                if(event.key.key == SDLK_LEFT) state.bMoveLeft = false;
                else if(event.key.key == SDLK_RIGHT) state.bMoveRight = false;
                else if(event.key.key == SDLK_UP) state.bMoveUp = false;
                else if(event.key.key == SDLK_DOWN) state.bMoveDown = false;
            }
            else if(event.type == SDL_EVENT_MOUSE_BUTTON_DOWN)
            {
                mLog.msg(LL_INFO, "  Mouse clicked: button %d at %d, %d\n", event.button.button, (Sint32)event.button.x, (Sint32)event.button.y);
            }
        }

        if(!bRunning) break;
        state.fMouseX = mC64.cursorMgr().getX();
        state.fMouseY = mC64.cursorMgr().getY();
        updateLogic(state, pPlayerImage, 1.0f / static_cast<float>(iLogicRate));
    }

    // Close resources owned by this tutorial.
    mLog.msg(LL_INFO, "\nCLEANUP\n");
    mLog.msg(LL_INFO, "  Close debug window ... ");
    mC64.guiMgr().close(state.idDebugWindow);
    logTaskOk(mLog);
    mLog.msg(LL_INFO, "  Close images ... ");
    mC64.imageMgr().close(0);
    logTaskOk(mLog);
    mLog.msg(LL_INFO, "  Inspect CDC archive ... ");
    const Sint32 idCDC = mC64.archiveMgr().load(OUTPUT_CDC);
    if(idCDC < 0)
    {
        logTaskFailed(mLog, idCDC);
        Main::terminate();
        return -1;
    }
    logTaskOk(mLog);
    mC64.archiveMgr().info();
    mLog.msg(LL_INFO, "  Close CDC archive ... ");
    mC64.archiveMgr().close(idCDC);
    logTaskOk(mLog);
    Main::terminate();

    return 0;
}

Navigation

Previous: Tutorial 01 - Basic application setup

Back to the tutorials index

The next tutorial opens the configuration screen and stores its settings in the shared CDC archive.

Continue with Tutorial 03: Configuration
